14V DC 30A SPST 4-Pin Fused Relay w/ Wire Harness Kit

Product Code: PSZACCEPS179R

Free Standard Shipping

In stock

Ships today if ordered in the next 3 hours and 28 minutes! Please contact us for ETA

  • Fuse-On-Relay Design w/ 30A Fuses
  • Bosch Style 4-Pin SPS Relay
  • 30A High Switching Capability
  • Wire Specifications: Black - Ground (85)/ Red - VDC (30)/ White - Trigger (86)/ Blue - Output N/O (87)
  • Includes 6 Fused Relays & Harnesses
Read More

Free Shipping

1 Year Warranty

Details

Lights not working because of a burned out relay? Replace your relay and get back on the road with this new 4-pin 30A fused relay.

What's Included?

  • (6) 4-Pin 14-18 AWG Harness
  • (6) 4-Pin 30A Fused Relay
  • (1) Instruction Manual

Packed with features:

  • Fuse-On-Relay Design w/ 30A Fuses
  • Bosch Style 4-Pin SPS Relay
  • 30A High Switching Capability
  • Wire Specifications: Black - Ground (85)/ Red - VDC (30)/ White - Trigger (86)/ Blue - Output N/O (87)
  • Includes 6 Fused Relays & Harnesses

Basic

MPN:
EPS179R

Warranty & Certification

Warranty:
1 Year

Hardware & Install

Mounting Type:
Bracket-Mount
Mounting Hardware:
Fasteners
Housing Material:
Plastic
Operating Temperature:
-40°C ~ +85°C
Is Waterproof?:
No

Package & Dimension

Length (In):
5.88
Width (In):
1.25
Height (In):
1.13

Mechanical

Terminal Material:
Silver Plated Copper
Number of Prongs:
4.00
Pole Type:
Single
Throw Type:
Single
Release Time:
5msec max
Terminal Type:
.250" Quick Disconnect
NO/NC:
NO

Electrical

Max Switching DC Voltage:
12V DC
Max Switching Power:
360.00
Dielectric Strength:
AC 1500V 1 minute
Trigger Coil Current:
1.50
Coil Resistance:
80.00
Has Flyback Diode?:
No
Has Resistor?:
No
