16-Inch 12-LED Trailer Identification Light Bar w/ TBT Function - Red

Product Code: CAZLEDTBL1520-RD
Rating:
100% of 100
Price: $24.99

Free Standard Shipping

In stock

Ships tomorrow if ordered in the next 23 hours and 17 minutes! please contact us for ETA

  • DOT FMVSS-108 Approved
  • SAE S2I6U2PS Rated
  • TBT Function w/ Sequential Turn Signals
  • IP67 Waterproof (Submersible)
  • Premium Reflector Design
  • Solid Construction
  • Suitable for 80” or wider Applications
Read More

Free Shipping

1 Year Warranty

Details

Brake Light & Turn Signal Functionality In A Single DOT-Approved Id Bar

Graced with DOT FMVSS-108 certification, our 16-Inch trailer ID bar is a simple-to-install, highly-functional way to attract extra visibility to your 80" or wider trailer. Its reflective red lens is engineered to alert other motorists of your presence as well as maximize your on-road safety. But that’s not all: this is the industry’s first trailer ID bar featuring built-in brake light and turn signal functionality!

Waterproof & Submersible Design Stands Up To All-Weather Abuse

Sporting an IP67 waterproof and fully-submersible construction, this LED ID bar is designed to resist water and dust intrusion for exceptional all-weather durability that cheaper ID bars can only dream of. Additionally, all the metal fasteners on the unit are sealed for additional protection against inclement weather.

User-Friendly Installation Is A Breeze

This ID clearance light bar is designed to be easily installed by users of all mechanical aptitude. Features like color-coded wiring make installation safer and simpler. Additionally, detailed instructions are provided to help clarify the installation process.

What's Included?

  • (1) 16" Trailer Identification Light Bar
  • (1) Pack of Screws
  • (1) Instruction Manual

Packed with features:

  • DOT FMVSS-108 Approved
  • SAE S2I6U2PS Rated
  • TBT Function w/ Sequential Turn Signals
  • IP67 Waterproof (Submersible)
  • Premium Reflector Design
  • Solid Construction
  • Suitable for 80” or wider Applications

Basic

MPN:
TBL1520-RD

Warranty & Certification

Certification Detail:
SAE I6 P2 S2 (3)T DOT FMVSS-108
IP Rating:
IP67
Warranty:
1 Year

Lighting

LED Type:
3528 SMD
Light Color:
Red
LED Wattage:
6.00
Number of LEDs:
12.00

Hardware & Install

Connector Type:
Pigtail
Lens Cover Color:
Red
Lens Cover Material:
Acrylic
Mounting Type:
Surface-Mount
Mounting Hardware:
Fasteners
Wire Length (In):
17.00
Housing Material:
ABS
Operating Temperature:
-30°C~+50°C
Is Waterproof?:
Yes

Package & Dimension

Length (In):
15.88
Width (In):
1.13
Height (In):
1.38

Electrical

Amperage:
2.50
Operating Voltage:
8-16V DC
Power Output (Watt):
30.00
