5pc 14V DC 80/60A SPDT Bosch Style 5-Pin Relay + Harness Base w/ Wires Kit

Product Code: PSZACCEPS180R

Free Standard Shipping

In stock

Ships today if ordered in the next 4 hours and 53 minutes! Please contact us for ETA

  • Bosch Style 5-Pin SPDT Relay
  • 80A/60A High Switching Capability
  • Wire Specifications: Black - Ground (85)/ Red - VDC (30)/ White - Trigger (86)/ Yellow - Output N/C (87a)/ Blue - Output N/O (87)
  • Includes 5 Relays & Harnesses
Read More

Free Shipping

1 Year Warranty

Details

PSZACCEPS180R Heavy Duty 5-pin SPDT Bosch style relay is rated to handle 80 amps of load at 12V DC in the normally open position, and 60 amps of load at 12V DC in the normally closed position. The spade terminals for the main contacts are sized at 3/8 inch, ensuring the capability of the relay to handle high current loads. These heavy duty relays are offered with relay socket/harness, which features interlocking mechanism for ease of installation. Metal tabs are present on the relay for secure mounting. Set includes 5 relays and 5 relay harnesses.

What's Included?

  • (5) 5-Pin 80/60A Relay
  • (5) 5-Pin 12-16 AWG Harness
  • (5) Mounting Plate
  • (1) Instruction Manual

Packed with features:

  • Bosch Style 5-Pin SPDT Relay
  • 80A/60A High Switching Capability
  • Wire Specifications: Black - Ground (85)/ Red - VDC (30)/ White - Trigger (86)/ Yellow - Output N/C (87a)/ Blue - Output N/O (87)
  • Includes 5 Relays & Harnesses

Basic

MPN:
EPS180R

Warranty & Certification

Warranty:
1 Year

Hardware & Install

Mounting Type:
Bracket-Mount
Mounting Hardware:
Fasteners
Housing Material:
Plastic
Operating Temperature:
-40°C ~ +85°C
Is Waterproof?:
No

Package & Dimension

Length (In):
1.63
Width (In):
1.13
Height (In):
1.25

Mechanical

Terminal Material:
Copper
Number of Prongs:
4.00
Pole Type:
Single
Throw Type:
Double
Release Time:
5msec max
Terminal Type:
.250" Quick Disconnect

Electrical

Max Switching DC Voltage:
12V DC
Max Switching Current:
80A
Max Switching Power:
960.00
Dielectric Strength:
AC 1500V 1 minute
Trigger Coil Current:
1.50
Coil Resistance:
80.00
Has Flyback Diode?:
No
Has Resistor?:
No
