8' CRUIZER 1-To-2 Wiring Harness w/ 30A SPST On/Off Rocker Switch - Red

Product Code: ORZLEDCTL001
by LAMPHUS
Rating:
100% of 100
Price: $9.99

Free Standard Shipping

In stock

Ships tomorrow if ordered in the next 17 hours and 55 minutes! Please contact us for ETA

  • IP65 Waterproof Rating
  • Illuminated On/Off SPST Switch
  • 25A Max @ 12VDC
  • 8ft 12AWG Wiring w/ Inline Fuse & Relay
Read More

Free Shipping

1 Year Warranty

Details

Command Complete Control Over Your LED Accessory Lights

Fully-loaded with a potent 40 Amp relay, 30 Amp blade fuse, and 25 Amp water/dustproof On/Off switch with illumination, the LAMPHUS LED Light Bar Wiring Harness Kit places convenient control over all LED light bars & work lights at your fingertips. Our automotive LED light bar wiring harness kit will safely power LED light bars, work lights & accessory lighting of up to 50" or 300W on your truck, SUV, ATV & more.

Simplifies The Installation Process For Off-Road LED Light bars, Work Lights & More

Sporting over 8ft of wiring, industry-standard .250" insulated power connectors, and a rugged mounting bracket, this light bar wiring kit dramatically cuts down on LED light bar installation time. The On/Off switch only requires a 7/16" hole to be drilled on the mounting surface, making this wiring harness setup one of the cleanest & simplest.

Built To Exceed Your Discerning Quality Expectations

Armed with a 40A power relay and 30A blade fuse, these components effectively protect the circuit when overcurrent or short circuit occurs. This LED light bar wiring harness also flaunts an IP65 rated rocker switch, protecting your electrical system (and LED lights) from harmful water and dust intrusion.

What's Included?

  • (1) 1-2 Wiring Harness, Bundle of Black/Red Wires, and 16-14 AWG Push-On Terminals
  • (1) 25A SPST Switch
  • (1) Switch Panel
  • (1) Instruction Manual

Packed with features:

  • IP65 Waterproof Rating
  • Illuminated On/Off SPST Switch
  • 25A Max @ 12VDC
  • 8ft 12AWG Wiring w/ Inline Fuse & Relay

Basic

Brand:
LAMPHUS
Model Name:
Cruizer
MPN:
ORWH01

Warranty & Certification

IP Rating:
IP65
Warranty:
1 Year

Hardware & Install

Connector Type:
TT-30P;5-15R
Wire Length (In):
96.00
Housing Material:
PVC
Operating Temperature:
-40°C~+105°C
Is Waterproof?:
Yes

Package & Dimension

Length (In):
1.38
Width (In):
1.50
Height (In):
1.38
