Premium LED Trailer Tail Light Kit for Over 80-Inch Trailers

Product Code: CAZLEDTBL1652

In stock

Ships tomorrow if ordered in the next 19 hours and 1 minutes! Please contact us for ETA

  • Turn/Brake/Tail Lights

  • Rear Side Marker Light

  • Rear and Side Reflectors

  • Internal Chrome Reflector

  • Center Diffused Lens

  • IP67 Waterproof

  • 20' Wire Harness, 16" Ground

  • Wishbone Style Harness

  • 4 Pin Connector

  • For Trailers Wider Than 80"

Read More

1 Year Warranty

Details

Your Safety, Your Time, You’re Covered

Installing dim tail lights is a waste of time, and who likes wasting their time? We don’t, that’s why we made sure that our lights are worth the (very little) effort it takes to install them. Built with 15 powerful rear-facing LEDs, three center-diffused lenses, a unique chrome reflector, and a side marker light that contains an extra rear facing LED, these lights take safety and visibility to a new level.

You Can Stop Searching

Trying to figure out what lights are required on your 80” or wider trailer? Well, here's your answer: brake and tail lights, turn signals, front/rear side marker lights, front/rear side reflectors, rear reflectors, a license plate light, front/rear clearance lights, and an identification light bar. Covering 7 of the 12 requirements in one unit, these lights are the first step towards getting your trailer on the road.

Simplified Install

Easy to see, easy to be legal, and easy to install. That’s right, our light kit takes the guesswork out of your tail light install. We include the wiring, clips, splice connectors, ring terminals, and nuts that you will need to install your new lights. We even designed our lights with two wiring exit points so that you can adjust to fit your needs.

Packed with features:

  • Turn/Brake/Tail Lights
  • Rear Side Marker Light
  • Rear and Side Reflectors
  • Internal Chrome Reflector
  • Center Diffused Lens
  • IP67 Waterproof
  • 20' Wire Harness, 16" Ground
  • Wishbone Style Harness
  • 4 Pin Connector
  • For Trailers Wider Than 80"

Basic

MPN:
TBL1652

Warranty & Certification

IP Rating:
IP67
Warranty:
1 Year

Lighting

LED Type:
Superflux Piranha
LED Wattage:
34.00
Number of LEDs:
34.00

Hardware & Install

Connector Type:
Pigtail
Lens Cover Color:
Red
Lens Cover Material:
Acrylic
Mounting Type:
Surface-Mount
Mounting Hardware:
Fasteners
Wire Length (In):
15.00
Housing Material:
Polycarbonate (PC)
Operating Temperature:
-30°C~50°C
Is Waterproof?:
Yes

Package & Dimension

Length (In):
8.00
Width (In):
2.88
Height (In):
3.00

Electrical

Amperage:
0.81
Operating Voltage:
12V DC
Power Output (Watt):
9.84
